Document Library Module

The Document Library provides a shared transboundary repository for storing treaty documents, meeting minutes, maps, and CSV templates.

Folder & Document Schema

The database supports a recursive folder tree and document storage links:

  ┌────────────────────────────────────────────────────────┐
  │                        folders                         │
  │  - id (UUID)                                           │
  │  - name (string)                                       │
  │  - parent_id (UUID, references folders.id) ◄────────┐  │ (Recursive hierarchy)
  └───────────────────────────┬─────────────────────────┴──┘
                              │
                              ▼
  ┌────────────────────────────────────────────────────────┐
  │                       documents                        │
  │  - id (UUID)                                           │
  │  - file_name (string)                                  │
  │  - folder_id (UUID, references folders.id)             │
  │  - file_type (string)                                  │
  │  - file_size (integer)                                 │
  │  - uploaded_by_id (UUID, references users.id)          │
  │  - category (string)                                   │
  └────────────────────────────────────────────────────────┘

1. folders

A recursive model containing:

• name: Folder display name.
• parent_id: Reference to another folder. If null, it exists at the root level of the library.

2. documents

Stores metadata and path references for uploaded files:

• file_name: Original name of the uploaded document.
• file_type: Mime type (e.g. application/pdf, text/csv).
• uploaded_by_id: User who uploaded the file.
• category: Category tag (treaty, meeting_minutes, technical_report, map).

Upload & Storage Workflow

File uploads are managed by DocumentUploadController.php and the standard Laravel file storage configuration.

1. File Upload (store)

When a file is uploaded:

1. Validation: The controller validates file constraints (maximum size, permitted extensions: PDF, CSV, Excel, DOCX).
2. Storage Disk: The file is saved to the local disk:

   $path = $request->file('file')->store('library-documents');

3. DB Logging: A new record is written to documents containing the storage reference path.

2. File Download (download)

• To prevent exposure of local directory paths, files are served via a gated Laravel route: GET /library/documents/{document}/download.
• The controller resolves the document path, verifies user credentials, and returns a streamed download file response:

  return Storage::download($document->file_path, $document->file_name);
